High Performance
• Maximum door area up to 60㎡
• Soft start, soft stop
• LCD plain-text display
• Automatic calibration: quick, hassle-free setup
Technical Parameters
| Voltage | 110-120VAC 50 / 60Hz |
| Motor power in W | 400 / 750 / 1000 |
| Rated output torque in Nm | 60 / 100 / 140 |
| Max. output in Nm | 80 / 120 / 180 |
| Speed in RPM | 5-50 |
| Diameter hollow shaft in mm | 25.44 / 31.75 |
| Endurance in c/h | 60 |
| Waterproof and Dustproof Rating | IP54(IP65available) |
| Limit setting of door travel | Absolute encoder |
| Emergency release | Chain hoist |
| Max. door area in ㎡ | 25 / 49 / 60 |
